Casio PCR-T273 - 6. Exploded View;Parts List Model: Se-G1;Pcr-T723;Sm-T274; Parts List

SE-G1/PCR-T273/SM-T274
– 27 –
6. EXPLODED VIEW/PARTS LIST
MODEL : SE-G1/PCR-T723/SM-T274
(EX-256)
<CONTENTS>
6-1. EXPLODE VIEW ............................................................................................... 28
6-2. PARTS LIST ...................................................................................................... 30
6-3. DRAWER S-type (DL-1335/1844/1845) ........................................................... 33
6-4 DRAWER M-type (DL-2816/2817).................................................................... 35
NOTES :
1. Price and specications are subject to change without prior notice.
2. As for spare parts order and supply, refer to the “GUIDEBOOK for Spare Parts Supply”, published
separately.
3. The numbers in item column correspond to the same numbers in drawing.
4. CASIO does not supply the spare parts without parts code.
5. Refer to the latest "Parts Price Code" at “PARTS FINDER” on the Casio Service WEB site
(https://www.servicecasio.com).
6. Remarks
Q’ty: Quantity used per unit
RANK: A = Essential
B = Stock recommended
C = Less recommended
X = No stock recommended
