Getting Ready
Prepare a household power outlet or batteries.
• Be sure to comply with the “Safety Precautions”
provided in the separate “READ THIS!” sheet.
Incorrect use of this product creates the risk of
electric shock and fire.
• Always make sure that the Digital Keyboard is
turned off before plugging in or unplugging the AC
adaptor, or before loading or removing batteries.
Make sure that you use only the AC adaptor specified for
this keyboard. Use of a different type of AC adaptor can
cause malfunction.
* Check with your dealer for the name of the AC adaptor
to be used.
• The AC adaptor will become warm to the touch
after very long use. This is normal and does not
indicate malfunction.
• To prevent breaking of the wire, take care to avoid
putting any type of load on the power cord.
Use 6 commercially available size AA alkaline batteries
or NiMH rechargeable batteries.
• Commercially available size AA manganese batteries
can also be used, but because some types of usage
may require high power consumption, the use of
alkaline batteries or NiMH rechargeable batteries is
recommended.
Note the precautions below when using rechargeable
batteries.
• Use Panasonic Group AA-size eneloop rechargeable
batteries. Do not use any other type of batteries.
• Use only the specified charger to charge batteries.
• Rechargeable batteries must be removed from the
product for charging.
• For information about using eneloop batteries or their
specified charger, be sure to read the user
documentation and precautions that come with each
item, and use them only as directed.
Open the battery cover on the bottom of the Digital
Keyboard, load the batteries, and then close the cover.
• Take care to ensure that the positive
+
and negative
-
ends of the batteries are facing correctly.
• Battery life is approximately 12 hours of
continuous use (based on alkaline batteries,
normal play). Any of the symptoms below may
indicate batteries are low and need to be replaced
as soon as possible.
• The Digital Keyboard will turn off automatically to
preserve battery power if you do not perform any
operation for about six minutes (Auto Power Off).
Hold down the TONE button while turning on the
keyboard to disable Auto Power Off.
Power Supply
Using a Household Power Outlet
CASIO
Specified AC Adaptor:
AD-E95100LE/LG/LJ/LU/LW*
(JEITA Standard plug)
No bending! No winding!
Household power outlet
Using Batteries
● Dim display. ● Distorted sound.
● Keyboard tones, songs or rhythms are played when no
buttons or keys are pressed.
● Abnormal play of built-in songs, etc.
● Sudden, unexpected failure of notes to sound.
Open the battery
cover. Load the batteries.
Pressing here,
slide in the
direction
indicated by the
arrow.
● Any reproduction of the contents of this manual, either in part or its entirety, is prohibited. Except for your own, personal use, any
other use of the contents of this manual without the consent of CASIO is prohibited under copyright laws.
● IN NO EVENT SHALL CASIO BE LIABLE FOR ANY DAMAGES WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES
FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, LOSS OF INFORMATION) ARISING OUT OF THE USE OF OR INABILITY
TO USE THIS MANUAL OR PRODUCT, EVEN IF CASIO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
● The contents of this manual are subject to change without notice.
● The actual appearance of the product may be different from that shown in the illustrations in this User’s Guide.
● Company and product names used in this manual may be registered trademarks of others.
MA2203-B Printed in China
C
USER’S GUIDE
GUÍA DEL USUARIO
Please keep all information for future reference.
Guarde toda información para tener como referencia futura.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Important Information for Parents!
Parents should please note the following important information before letting children use this product.
•
Before using the AD-E95100LE/LG/LJ/LU/LW adaptor to power the unit, be sure to check the AC adaptor for any damage first. Carefully check
the power cord for breakage, cuts, exposed wire and other serious damage. Never let children use an AC adaptor that is seriously damaged.
• Never mix batteries of different types.
• Never mix old batteries with new ones.
• Use recommended batteries or equivalent types.
• Always make sure that positive (+) and negative (–) poles are
facing correctly as indicated near the battery compartment.
• Replace batteries as soon as possible after any sign they are
getting weak.
• Do not short-circuit the battery terminals.
• The product is not intended for children under 3 years.
• Use only CASIO AD-E95100LE/LG/LJ/LU/LW adaptor.
• Be sure to disconnect the AC adaptor before cleaning the
product.
Be sure to read the “Safety Precautions” in the separate
“READ THIS!” sheet, and use the product correctly.
NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the
equipment.
EN/ES
Manufacturer:
CASIO COMPUTER CO., LTD.
6-2, Hon-machi 1-chome, Shibuya-ku, Tokyo 151-8543, Japan
Responsible within the United Kingdom:
Casio Electronics Co. Ltd.
10 Norwich Street, London, EC4A 1BD, U.K.
www.casio.co.uk
Manufacturer:
CASIO COMPUTER CO., LTD.
6-2, Hon-machi 1-chome, Shibuya-ku, Tokyo 151-8543, Japan
Responsible within the European Union:
Casio Europe GmbH
Casio-Platz 1, 22848 Norderstedt, Germany
www.casio-europe.com
General Guide
General Guide
a
1.
Set
(P) to “ON”.
The Digital Keyboard switches on.
2.
Use
(Keyboard) to make a sound.
3.
Use
(VOLUME) to adjust the volume.
1.
Press
(TONE).
2.
Choose your favorite tone from the
(Tone list) or from the tone list in this
User’s Guide, and then enter its number
using the numbers or the plus (
+
) and
minus (–) buttons
.
• For example, to select “05 ELEC PIANO 2”, press
“0” and then “5”.
• You can also use plus (
+
) and minus (–) buttons to
change the number. (“
+
” increases the number
and “–” decreases the number.) Holding the button
down changes the number continuously.
• Press “
+
” and “–” at the same time to return to the
original setting.
3.
Use
(Keyboard) to play the tone you
chose.
• You can use
(PIANO, TRUMPET, DRUMS) to
quickly and easily select the GRAND PIANO (00),
TRUMPET (50) and DRUM SET (99) tones.
1.
Press
(METRONOME).
The metronome starts up.
2.
Press
(METRONOME) again to stop the
metronome.
• For information on how to change the metronome
tempo, see “Changing the Speed (Tempo) of a
Rhythm or Built-in Song”.
bn
OCTAVE
–
/+
bo
TEMPO yt
bp
METRONOME
bq
FUNCTION
br
START/STOP
7
TONE
4
VOLUME
9
SONG
8
RHYTHM
Speaker
Speaker
LCD panel
Rhythm list
Tone list
Keyboard
Tone buttons (PIANO, TRUMPET, DRUMS)
Numbers, –/
+
Back
PHONES/OUTPUT
jack
DC 9.5V
terminal
Song list
P (Power)
Playing Something on the Digital
Keyboard
Playing Using Tones
TONE
Tone number
Playing Using the Metronome
You can use the procedure below to configure the
settings so that the Digital Keyboard sounds a chime on
the first beat of each measure and a click on the
remaining beats.
1.
Press
(FUNCTION) repeatedly until
“BEAT” appears on the LCD panel.
2.
Use the numbers or the plus (
+
) and minus
(–) buttons
to enter the beat.
• Choose a beat setting from 0-9.
• If you choose “0”, no chime sounds on the first
beat.
• The original display returns after a few moments.
You can have rhythms from various musical genres play
as backing while you play the Digital Keyboard.
1.
Press
(RHYTHM).
2.
Choose your favorite rhythm from
(Rhythm list) or from the rhythm list in
this User’s Guide, and then enter its
number using the numbers or the plus (
+
)
and minus (–) buttons
.
• The procedure for entering the number is the same
as for tone numbers.
3.
Press
(START/STOP) to play the rhythm
you chose.
• To stop the rhythm, press
again.
• For information on how to change the tempo of the
rhythm, see “Changing the Speed (Tempo) of a
Rhythm or Built-in Song”.
1.
Press
(SONG).
2.
Choose a song from
(Song list) and then
enter its number using the numbers or the
plus (
+
) and minus (–) buttons
.
• When using numbers to choose a song, start by
entering “0”. The procedure for entering the
number is the same as for tone numbers.
• To listen through all the songs, display “AL” on the
LCD panel. To display “AL”, either use the plus (
+
)
and minus (–) buttons, or just press one of the
number buttons “1-9” without first pressing “0”.
3.
Press
(START/STOP) to play the song
you chose.
• To stop the song, press
again.
• For information on how to change the tempo of the
rhythm, see “Changing the Speed (Tempo) of a
Rhythm or Built-in Song”.
• If you change the tempo, tone or any other setting for a
song while listening to all the songs “AL”, the changed
song settings revert to their initial values when the next
song is played.
1.
Hold down
(SONG).
This mutes the melody for built-in songs.
2.
Press
(START/STOP).
The melody is not played, so you can play it yourself
on the keyboard
.
Changing the Beat
Playing Using a Rhythm
Beat
RHYTHM
Rhythm number
Listening to Built-in Songs
Muting the Song Melody So You Can Play it
Yourself
SONG
Song number
SONG
“M” lights
Reference
● There is no sound when I press keyboard
keys.
• Check to make sure batteries are loaded or that the
AC adaptor is connected correctly. (See “Power
Supply”.)
• Unplug the plug from the
(PHONES/OUTPUT) jack
if one is connected.
● Sound and display operations are not
normal.
• Battery power may be low. See “Power Supply”.
* Measured values while using eneloop batteries.
eneloop is a registered trademark of Panasonic Corporation.
• Design and specifications are subject to change
without notice.
• You can get information about accessories that are
separately for this product from the CASIO keyboard
catalog available from your retailer, and from the
CASIO website at the following URL.
https://world.casio.com/
For information about the product and its music scores,
visit the CASIO website.
https://support.casio.com/global/en/emi/manual/SA-50/
Troubleshooting
Specifications
Keyboard
:
32 mini-size keys, 2.5 octaves
Polyphony
:
32 notes maximum
Tones
:
100
Preset Rhythms
:
50
Preset Songs
:
10 tunes; melody off
Tuning
:
A4 = 416 to 440 to 465 Hz
Speakers
:
φ
8 cm × 2 (output: 0.5 W + 0.5 W)
Power Jack
:
DC 9.5V
Phones/Output jack:
Stereo mini jack
Output Impedance: 120 Ω
Output Voltage: 500 mV (RMS) MAX
Power Supply : 2-way
Power Consumption: 9.5 V = 3.2 W
Dimensions : 44.6 × 20.8 × 5.1 cm
(17
9
/16 × 8
3
/16 × 2 inch)
Weight : Approximately 1.0 kg (2.2 lbs)
(without batteries)
•
Key 99:DRUM SET
F2 Synth Kick
F{2 Synth Snare 1
G2 Synth Snare 2
G{2 Dance Kick 2
A2 Dance Kick 1
B}2 Dance Snare 1
B2 Dance Snare 2
C3 Dance Clap
C{3 Snare 3
D3 Brush Snare Slap
E}3 Brush Snare Sweep
E3 Kick 2
F3 Kick 1
F{3 Side Stick
G3 Snare 1
G{3 Closed Hi-Hat
A3 Snare 2
B}3 Open Hi-Hat
B3 Low Tom
C4 Mid Tom
C{4 Crash Cymbal
D4 High Tom
E}4 Ride Cymbal
E4 Xiao Luo
F4 Vibraslap
F{4 Tambourine
G4 Maracas
G{4 Triangle Open
A4 Triangle Close
B}4 Claves
B4 Mute Cuica
C5 Open Cuica
C{5 Mute High Conga
D5 Open High Conga
E}5 Open Low Conga
E5 High Agogo
F5 Low Agogo
F{5 High Whistle
G5 Low Whistle
G{5 Tabla Ge
A5 Tabla Ka
B}5 Tabla Te
B5 Tabla Na
C6 Tabla Tun
C{6 High Timbale
D6 Low Timbale
E}6 High Bongo
E6 Low Bongo
F6 Long Guiro
F{6 Short Guiro
G6 Cowbell
G{6 High Wood Block
A6 Low Wood Block
B}6 Cabasa
B6 Shaker
C7 Hand Clap
General Guide
1.
Press
(TEMPO yt).
2.
Change the tempo value by using
(TEMPO yt) or the plus (
+
) and minus
(–) buttons
.
• You can change the tempo in increments of 10
using
(TEMPO yt) or in single increments
using the plus (
+
) and minus (–) buttons
.
• You can set any value between 20 and 255.
• The original display returns after a few moments.
1.
Press
(OCTAVE –/
+
).
2.
Use
(OCTAVE –/
+
) to change the shift
amount.
• You can set any value between –1 and +1 octaves.
• The original display returns after a few moments.
Use the procedure below to change the function settings.
1.
Press
(FUNCTION).
• The setting changes each time you press
(FUNCTION).
2.
Use the numbers or the plus (
+
) and minus
(–) buttons
to enter a value.
• Press “
+
” and “–” at the same time to return to the
original setting.
• The original display returns after a few moments.
You can adjust the pitch of all the Digital Keyboard’s
tones using the A4 tone as the standard (in 1 Hz
increments).
1.
Press
(FUNCTION) repeatedly until
“TUNING” appears on the LCD panel.
2.
Use the numbers or the plus (
+
) and minus
(–) buttons
to enter a tuning value.
• You can set any value between 416 and 465 Hz.
• The original display returns after a few moments.
Changing the Speed (Tempo) of a
Rhythm or Built-in Song
Changing the Pitch of the Sound in
Octaves (Octave Shift)
Tempo value
Shift amount
Changing the Function Settings
Setting Display Values set
Tuning TUNING 416 to 465
Reverb REVERB ON, OFF
Beat BEAT 0 to 9
Transposition TRANS. –12 to 0 to +12
Fine Tuning the Pitch (TUNING)
Setting
Tuning value
Transposition shifts the overall pitch of the sound in
semitone increments.
1.
Press
(FUNCTION) repeatedly until
“TRANS.” appears on the LCD panel.
2.
Use the plus (
+
) and minus (–) buttons
to change the value set.
• You can shift the pitch up and down by one octave
(max. –12 to +12 semitones).
• The original display returns after a few moments.
You can use the procedure below to add reverb to the
notes you play.
1.
Press
(FUNCTION) repeatedly until
“REVERB” appears on the LCD panel.
2.
Press the plus (
+
) and minus (–) button in
to turn reverb ON and OFF.
(
+
: ON, –: OFF)
• The original display returns after a few moments.
You can adjust the contrast of the LCD panel.
1.
Hold down
(FUNCTION) and press “0” in
.
2.
Use the numbers or the plus (
+
) and minus
(–) buttons
to enter a value.
• You can set any value between 1 and 8.
3.
Press
(FUNCTION) again to complete
the setting.
• The LCD contrast setting is retained even if you switch
the Digital Keyboard off.
When you turn the Digital Keyboard off, all settings such
as the tone numbers and song numbers revert to their
original settings. You cannot save your settings before
turning the Digital Keyboard off.
Connect headphones or audio equipment to the PHONES/
OUTPUT jack on the back of the Digital Keyboard.
• If the plug you are using does not match the jack, use
a commercially available adaptor plug.
• Do not listen to very high volume output over
headphones for long periods. Doing so creates the
risk of hearing damage.
• When connecting a musical instrument amplifier,
set the Digital Keyboard volume to a low level and
use the amplifier’s volume control to adjust to the
desired volume level.
Adjusting the Pitch of the Sound in Semitone
Increments (Transposition)
Using Reverb
Values set
ON/OFF
Making the Screen Easier to See
Settings at Power Off
Using Headphones or Audio
Equipment
Values set
Commercially available headphones
Stereo mini plug
Commercially available connecting cord
PHONES/OUTPUT jack
Audio equipment,
amplifier, etc.
General Guide
To Next Page
Loading...
Need help?
General
Weight and Dimensions
