5 Instructions for Use
1. With the clamp lever in the material loading
position, place stock to be pocketed on the
work deck under the clamping plate and
squarely against the rear fence. (Figure 5a)
2. Place the clamp lever in the stock thickness
adjustment position. The half-moon cutout on the
clamp lever will align with the top of the 110 as
shown in figure 5b.
3. Turn the stock thickness adjustment knob
clockwise until the clamping plate firmly
touches the workpiece. (Figure 5c)
