CAT INV2000 - COMPONENT IDENTIFICATION

7
COMPONENT IDENTIFICATION
1) Vacuum Relief Valve
2) Fuel Cap
3) Panel Light
4) Recoil Starter
5) Fuel Gauge
6) Spark Plug Cover
7) Spark Arrestor
8) Oil Gauge / Oil Fill / Oil Drain*
9) Air Filter Assembly*
10) Generator Switch
11) Engine Smart Control (ESC) Switch
12) Display LEDs
13) Receptacle – 120 VAC double GFCI
14) AC Circuit Breaker
15) Ground Terminal
16) Parallel Receptacles
17) Receptacle – USB double
18) Receptacle – 12VDC 8.3A
19) DC Circuit Breaker
*behind service access door
1
2
4
3
5
6
7
8
9
10
11
17
18
19
13
16
14
15
12
