110
180
830
110
830
180
180
For wall-outlet installation, place the pipe fittings as shown
Fasten fixing sets to the floor
Place the WC, then fasten it using the supplied smallware
Place the cistern on the WC, after the installation of the lip-shaped seal
Fasten the cistern to the wall
For floor-outlet installation, place the pipe fittings as shown
Connect flex hose to cistern stop tap
Place the cistern cover into position
