TEST PANEL (for PRS300)
2
COLLEGAMENTI - CONNECTIONS
L’installazione pessere effettuata ad incasso
o a parete con il distanziale in dotazione.
Dimensioni: 60x60mm.
Built-in installation or wall fixing with the spacer
supplied.
Size: 60x60mm.
IT
EN
Installation par encastrement ou par fixation au
mur avec l'entretoise fournie en standard.
Dimensions : 60x60mm.
Die Installation kann eingebaut oder an der
Wand mit dem mitgelieferten Distanzstück
durchgeführt werden.
Abmessungen: 60x60mm.
DE
FR
INSTALLAZIONE - INSTALLATION
Fissaggio ad incasso
Built-in fixing
Fixation encastrée
Wandeinbau
Fissaggio a parete
Wall-fixing
Fixation murale
Wandbefestigung
P T 64 2
11
2
3
4
