4.2 Definitions of the registers
Description of service and factory registers
Register
Name
Range
Description Default Value
01 HSh
00
63
Horizontal shift 45
02 VSD
00
00
Vertical screen 0
03 VSl 00
63
Vertical slope 30
04 VAm
00
63
Vertical amplitude 44
05 VSh
00
63
Vertical shift 32
06 SC
00
63
S-correction 14
The registers bellow must be set to the default values.
Register
Name
Range
Description Default Value
10 TWBl
00
255
Timing of ‘wide blanking’ 88
11 PWLi 00
63
Peak white limiting 08
12 OSIF 00
63
Off-set IF demodulator 20
13 HzPl 00
63
Horizontal parallelogram 32
14 HBow
00
63
Horizontal bow 32
15 HSh
00
63
Horizontal shift 45
16 EW
00
63
EW width 34
17 PW
00
63
EW parabola/width 35
18 EWUC
00
63
EW upper corner parabola 35
19 EWLC
00
63
EW lower corner parabola 35
20 TC
00
63
EW trapezium 33
21 VSl 00
63
Vertical slope 30
22 VAm
00
63
Vertical amplitude 44
23 SC
00
63
S-correction 14
24 VSh
00
63
Vertical shift 32
25 VX 00
63
Vertical zoom 25
26 VOT
00
63
Vertical Offset 28
27 TAS
00
63
Text Area Start 13
28 OEA
00
127
Odd Even Alignment 60
29 BLOR
00
63
Black level offset R 32
30 BLOG
00
63
Black level offset G 32
31 WPR
00
63
White point R 32
32 WPG
00
63
White point G 32
33 WPB
00
63
White point B 32
34 PkFr 00
3 Peaking Frequency 1
35 YDl 00
15
Luminance delay time 10
36 AGC
00
63
AGC take-over 25
37 CDc0
00
15
Colour decoder 0 6
38 CDc1
00
7 Colour decoder 1 0
39 AVS0
00
127
AV-switch 0 64
40 AVS1
00
7 AV-switch 1 0
41 Syn0 00
127
Synchronisation 0 0
42 Syn1 00
63
Synchronisation 1 16
