CCE HPS-2971 - Main Power Supply Voltages; Main Power Supply Regulation

HPS-2971
Condition Minimum Nominal Maximum Unit
117V
AC
“PP” - - 135,00 W
117V
AC
Stand-By - - 1,50 W
234V
AC
“PP” - - 135,00 W
234V
AC
Stand-By - - 1,50 W
3.2.2 Main Power Supply
a) Connect the TV set under test to 110Vac/60Hz line.
b) Turn on the TV and apply a 60dBµV signal (frequency and channel defined
by factory) 88% modulated with white pattern and audio signal with 400Hz
frequency modulated in FM with ±25kHz of deviation.
c) Adjust the TV to a “PP” condition.
d) Utilizing an electronic DC voltmeter (over 10 M input impedance), read the
next point in the power supply.
Condition Test Point Minimum Nominal
Maximum
Unit
“PP” 117V
AC
+B (Cathoe of D807) 130,50 132,50 134,50 V
DC
“PP” 117V
AC
Áudio (Cathode of D808) 20,00 22,00 24,00 V
DC
“PP” 117V
AC
Tuner (Cathode of DZ101) 30,00 33,00 36,00 V
DC
“PP” 117V
AC
+5V (Emitter of Q101) 4,50 5,00 5,50 V
DC
“PP” 117V
AC
+3V3 (Emitter of Q804) 3,00 3,30 3,60 V
DC
“PP” 117V
AC
+8V6 Áudio (Emitter of Q805) 8,00 8,60 9,00 V
DC
“PP” 117V
AC
+8V Video (Cathode of DZ807) 7,60 8,00 8,60 V
DC
3.2.3 Main Power Supply Regulation with fluctuation of the line
Repeat the procedure of the item 1 when the television is connected to the
electric net with 100VAC/60Hz and also 220VAC/60Hz.
Condition Test Point Minimum Nominal
Maximum
Unit
“PP” 240V
AC
+B (Cathode of D807) 130,50 132,50 134,50 V
DC
“PP” 240V
AC
Áudio (Cathode of D808) 20,00 22,00 24,00 V
DC
“PP” 240V
AC
Tuner (Cathode of DZ101) 30,00 33,00 36,00 V
DC
“PP” 240V
AC
+5V (Emitter of Q101) 4,50 5,00 5,50 V
DC
“PP” 240V
AC
+3V3 (Emitter of Q804) 3,00 3,30 3,60 V
DC
“PP” 240V
AC
+8V6 Áudio (Emitter of Q805) 8,00 8,60 9,00 V
DC
“PP” 240V
AC
+8V Vídeo (Cathode of DZ807) 7,60 8,00 8,60 V
DC
Condition Test Point Minimum Nominal
Maximum
Unit
“PP” 100V
AC
+B (Cathode of D807) 130,50 132,50 134,50 V
DC
“PP” 100V
AC
Áudio (Cahtode of D808) 20,00 22,00 24,00 V
DC
“PP” 100V
AC
Tuner (Cathode of DZ101) 30,00 33,00 36,00 V
DC
“PP” 100V
AC
+5V (Emitter of Q101) 4,50 5,00 5,50 V
DC
“PP” 100V
AC
+3V3 (Emitter of Q804) 3,00 3,30 3,60 V
DC
“PP” 100V
AC
+8V6 Áudio (Emitter of Q805) 8,00 8,60 9,00 V
DC
“PP” 100V
AC
+8V Vídeo (Cathode of DZ807) 7,60 8,00 8,60 V
DC
