f) Calculate the middle distances through blocks.
M = An/15.
Horizontal deviation between major blocks (DH
M
)
Read first the 15 blocks wide (from b1 to b15) and select the biggest read
(b
max
) for calculate the deviation:
DH
M
= b
máx
/M
Minor Horizontal deviation between blocks (DH
m
)
Read first the 15 blocks wide (from b1 to b15) and select the smallest read
(b
min
) for calculate the deviation:
DH
m
= b
mín
/M
(*)Check for signals PAL-M and PAL-N
PAL-M Minimum Nominal Maximum Unit
DH
M
- 1,10 1,30
DH
m
0,70 0,90 -
PAL-N Minimum Nominal Maximum Unit
DH
M
- 1,10 1,30
DH
m
0,70 0,90 -
