CCE HPS-2971 - Important Calibration Recommendations; Register Definitions

HPS-2971
4.1 Important recommendations
4.1.1 Before beginning the adjustments, the TV set should be a pre-heated during at
least 15 minutes.
4.1.2 The positioning of the TV set should obey the magnetic parameters of South
America that it is -120 vertical mG. In the practice, this is gotten with a relative
precision, positioning the TV set with the face (screen) of the CRT pointing to
the geographical East.
Note: These cares should also be taken when CQ will analyze the TV set.
4.2 Definitions of the registers
Register number
Name
Limits Description Default
01 HSh 00 63 Horizontal shift 32
02 VSD 00 00 Screen adjust 0
03 VSl 00 63 Vertical slope 30
04 VAm 00 63 Vertical amplitude 40
05 VSh 00 63 Vertical shift 42
06 SC 00 63 S-correction 25
07 HSh 00 63 Horizontal shift 32
08 EW 00 63 EW width 40
09 PW 00 63 EW parabola/width 32
10 TC 00 63 EW trapezium 32
11 HPlg 00 63 Horizontal parallelogram 32
12 Hbow
00 63 Horizontal bow 32
13 PWUC
00 63 EW upper corner parabola 32
14 PWLC
00 63 EW lower corner parabola 32
15 AGC
00 63 AGC take-over 25
16 VZom
00 63 Vertical zoom 25
*** This registers must be changed to default value.
Register number
Name
Limits Description Default
17 WBlk 00 255
Timing of ‘wide blanking’ 136
18 PWLi 00 63 Peak white limiting 15
19 OSIF 00 63 Off-set IF demodulator*** 20
20 VOT
00 63 Offset vertical*** 28
21 TAS
00 63 Text area start*** 13
22 OEA
00 127
Odd-Even aligment 60
23 BLOR
00 63 Black level offset R 32
24 BLOG
00 63 Black level offset G 32
25 WPR
00 63 White point R 32
26 WPG
00 63 White point G 32
27 WPB
00 63 White point B 32
28 PkFr 00 3 Peaking frequency 01
29 YDl 00 15 Luminance delay time 10
