CCE HPS-2971 - Page 59

IR RC SENSOR
TU101
TUNER
AUDIO / VIDEO
AUX INPUT
EHT
FOCUS & SCREEN
VOLTAGE
HORIZONTAL
DEFLECTION
CURRENT
IC301
TDA8177
VERTICAL OUTPUT
VERTICAL
DEFLECTION
CURRENT
132V
+25V
+15V
AKB
+205V
-15V
V901
CPT
IC701
CAT24WC08J
EEPROM
I²C BUS
I²C BUS
IC901
TDA6106
RGB AMP
AKB
IC901
TDA6106
RGB AMP
AKB
IC901
TDA6106
RGB AMP
AKB
HORIZONTAL
OUTPUT
CIRCUIT
+50V
IC601
TDA7496S
STEREO
AUDIO OUTPUT
IC60
TDA9855
AUDIO PROCESSOR
STEREO / SAP DECODER
+9V
I²C BUS
SF100
M1871M
SAW FILTER
SMPS
AGC
IF
IC101
TDA9573 - µCONTROLLER
IF PROCESSOR
Y/C PROCESSOR
SYNC PROCESSOR
STANDBY_L
29” TV MOD.:HPS-2971B
