378....7770 REV A 4-22-03
MOST COMMON CAUSES
OF APPARENT MALFUNCTION:
1. New Coach Odor: The glues and other materials used in
manufacturing the coach produce vapors which may be
detected when the coach is closed up on a warm day. Air
out the coach thoroughly.
2. Keeps Beeping: If the Gas Leak Detector appears to beep
about once every minute but the gas leak detector's orange
fault indicator is not lit, the problem may be a weak battery
in a
smoke detector or a Carbon Monoxide detector.
These devices produce short beeps that sound similar to
the sound of the Gas Leak Detector. These are high pitched
tones that bounce off hard surfaces, making their detection
very hard to pinpoint. Replace the battery in the smoke
detector and/or the Carbon Monoxide (CO) detector.
3. Hair spray triggers the detector: Most aerosol hair sprays
use butane gas as the propellant. Butane and propane have
similar characteristics. The detector is doing its job be-
cause butane is combustible.
4. Other Gases: Other gases which can cause the detector
to alarm include the vapors from any fuel, liquor, alcohol,
deodorants, colognes, perfumes, wine, adhesives, lac-
quer, and most cleaning agents.
5. Fault Mode: This is a malfunction. The fault indicator is the
Orange LED. It will be lit if the battery is low or in the event
that the circuitry fails.
6. Low Voltage: When voltage drops below 8.5 volts the
Orange LED will be illuminated.
After reviewing the above, if the problem still exists,
call CCI for assistance.
TESTING & TROUBLESHOOTING INSTRUCTIONS - MODEL 7770
Propane Gas Leak Detector for Recreational Vehicles
HOW TO TEST
THIS TEST MUST BE PERFORMED BY AN ADULT.
This detector must be operating for at least 60 seconds before
it can be tested. Expose the detector to gas
* and observe that
the alarm will begin to sound. The alarm will continue to sound
until:
A. The gas mixture at the detector returns to a safe level.
B. The mute button is pressed.
This test procedure must be repeated every week or
after the power has been interrupted for more than one
hour or every time the RV is taken on a trip, whichever
occurs first.
* One method of simulating gas is to use a butane lighter (i.e.:
BIC
TM
). DO NOT rotate the flint wheel. Just press on the gas
release button for three seconds while pointing the exit
nozzle into the gas sensing area and holding the butane
llighter no closer than 3/4 " from the detector gas sensing
area as shown in the illustration on the last page.
SERVICE
This detector contains no serviceable parts. Contact CCI
Controls if service is required. Contact your dealer for a
replacement detector. See your RV Dealer or a qualified
Gas Service Center should service be required. If they are
not available in your area, call CCI. DO NOT discard or
resell this detector. Do not open this detector. Warranty
voided if case opened.
THIS PRODUCT MADE IN THE UNITED STATES
5052 Cecelia Street
South Gate, CA 90280-3511
(800) 521-5228 FAX (323) 560-1136
Listing # 1P74
Tested by CSA
to UL 1484
Underwriters
Laboratories Inc.
CCI CONTROLS
www.ccicontrols.com
LIMITED WARRANTY
CCI Controls warrants the equipment described herein to be free from defects in
material and workmanship under normal use and service when installed and used in
accordance with all applicable federal, state and local laws and regulations. CCI Controls
sole obligation hereunder shall be limited to repairing or replacing the component or
components shown to have been defective at time of shipment or to have become
inoperative within the term of this warranty.
This warranty does not cover damage resulting from abuse, misuse, negligence, or
accident; nor from problems resulting from failure to comply with all applicable federal,
state and local laws and regulations or problems caused, in whole or in part, by alteration
or modification to the product. This warranty does not cover transportation to and from
service locations, loss of time or use, inconvenience, commercial loss, loss of use,
incidental charges or other consequential damages. Some states do not allowed the
exclusion or limitation of incidental or consequential damages, so the above limitation
or exclusion may not apply to you. This warranty shall be for the term of two year from
and after the date of the first sale by a dealer to the consumer. The consumer shall
produce the original sales contract or receipt to identify the date of purchase. This
product contains no serviceable parts. If you have questions as to servicing this
product, contact CCI Controls. This warranty is voided if the product 's casing is open.
The foregoing is the complete warranty for the product. CCI Controls expressly
disclaims all warranties which are not stated herein, including, to the extent permitted
by applicable law, any implied warranty of merchantability or fitness for a particular
purpose. This warranty gives you specific legal rights and you may also have other
rights which vary from state to state.
