Cecilware HWD2 - Page 10

7.0
15.3
1.3
0.7
12.0
29.0
29.7
9.3
Hot Water Dispenser - HWD5PC
Push Button with Portion control or Manual dispense
Electrical Specifications
MODEL NO WATTSVOLTS PHASE
& CYCLES
RECEPTACLE
Operational
MODEL NO
INITIAL
HEAT-UP TIME
BURST
CAPACITY
RECOVERY GALLONS
PER HOUR
TANK
CAPACITY
HWD5PC
1700120 1 PH. 50/60 Hz
P5-15
R5-15
5.0 Gal
HWD5PC
Heat-up time and Dispense rate based on Inlet water temperature at 68°F and
Dispense water temperature range 165°F to 200°F
3000240 1 PH. 50/60 Hz
P6-15
R6-15
VOLTS
120 (1.7 KW)
240 (3.0 KW)
6000240 1 PH. 50/60 Hz
P6-30
R6-30
240 (6.0 KW)
5.0
9.0
14.0
30-45 Min
2.0 Gals
20-25 Min
20-25 Min 15-20 Min
3.0 Gals
15-20 Min 10-15 Min
4.0 Gals
Water Connection
Water pressure: 20 - 90 PSI (69 - 621 KPA) Supplied with ¼ OD male flare fitting
Export units add "X" to Model No.
Specify Voltage and type of line cord required.
POWER CORD
(included)
Page -9-
