7.9
9.9
15.4
DRIP
TRAY
OVERFLOW
TUBE
DISPENSE
FAUCET
INLET
VALVE
HEATER
SWITCH
POWER
CORD
15.9
1.0
24.0
Hot Water Dispenser - HWD2
Tomlinson faucet Manual dispense
Electrical Specifications
MODEL NO WATTSVOLTS
PHASE
& CYCLES
POWER CORD
(included)
RECEPTACLE
Operational
MODEL NO
INITIAL
HEAT-UP TIME
BURST
CAPACITY
RECOVERY GALLONS
PER HOUR
TANK
CAPACITY
HWD2
1700120 1 PH. 50/60 Hz
P5-15
R5-15
20-25 Min
1.5 Gals
10-15 Min 4.5
2.8 Gal
HWD2
Heat-up time and Dispense rate based on Inlet water temperature at 68°F and
Dispense water temperature range 165°F to 200°F
3000240 1 PH. 50/60 Hz
P6-15
R6-15
15-20 Min
5-10 Min 8.02.0 Gals
VOLTS
120 (1.7 KW)
240 (3.0 KW)
Water Connection
Water pressure: 20 - 90 PSI (69 - 621 KPA) Supplied with ¼ OD male flare fitting
Export units add "X" to Model No.
Specify Voltage and type of line cord required.
