PROGRAMMABLE TIMER "TEACH ME" ADJUSTMENTS
This timer can be programmed from the push buttons to dispense different volumes of hot water.
PROGRAMMING INSTRUCTIONS FOR AUTOMATIC DISPENSE
1. Turn Power Switch ON.
2. PRESS and HOLD [red] STOP Button with one hand.
3. PRESS and HOLD [green] DISPENSE Button with other hand.
4. RELEASE [red] STOP Button ONLY.
5. Continue to HOLD [green] DISPENSE Button for 5 SECONDS, then RELEASE.
6. PRESS and RELEASE [green] DISPENSE Button. Product begins dispensing. When it reaches the
"DESIRED VOLUME",
7. PRESS and RELEASE [green] DISPENSE Button to SET "DESIRED VOLUME". DISPENSE Button can be
"jogged" to top off.
8. PRESS and RELEASE [red] STOP button to LOCK IN "DESIRED VOLUME". Repeat steps 1 to 8 for each
Dispense Button.
PROGRAMMING INSTRUCTIONS FOR MANUAL DISPENSE
1. Turn Power Switch ON.
2. PRESS and HOLD [red] STOP Button with one hand.
3. PRESS and HOLD [green] DISPENSE Button with other hand.
4. RELEASE [red] STOP Button ONLY.
5. Continue to HOLD [green] DISPENSE Button for 5 SECONDS, then RELEASE.
6. PRESS and RELEASE [red] STOP Button. Unit is in MANUAL DISPENSE mode.
