BONGO Z+ ON ROAD
BONGO Z+ OFF ROAD
BONGO Z+ ON ROAD
BONGO Z+ OFF ROAD
ENGLISH ENGLISH
ORIGINAL MANUAL TRANSLATION
Motor Max. power 1000 W
Rated power 500 W
Battery Type Lithium-Ion - 10INR19/66-
4
Model 95089
Charge time 7-8 hrs
Capacity 10000 mAh
Nominal voltage 48V
Max. charge voltage 54.6 V
Max. charging current 2A
Rated capacity 480 Wh
Tyres Tyre 10.5”
Charger Model CP546200
Input 100-240 V ~ 50/60 Hz
Outlet 54.6V - 2A
Protection IP 20; Ta= 40ºC; Class II
Riding modes and
autonomy (4)
PEDESTRIAN 27 km
NORMAL 52 km
SPORT 60 km
(1) Height from the oor to the upper part of the handlebar.
(2) Check the current local regulations.
(3) The autonomy has been measured with an 80 kg weight, completely charged battery,
Confort mode on a at surface, no wind, and a room temperature of approximately 25 ºC.
(4) It has been measured with an 80 kg weight, completely charged battery, at surface, no
Error codes
If any of the following error codes appear on the display, stop using the electric scooter
immediately and contact Cecotec’s ocial Technical Support Service.
- Error 1: throttle fault.
- Error 2: controller/communication fault.
- Error 3: battery protection/overvoltage.
- Error 4: brake fault.
8. TECHNICAL SPECIFICATIONS
Product reference: 07306/7
Model: Bongo Z+ On Road/O Road electric scooter
Features Measuring units Specications
Dimensions Folded 120x66x55 cm
Unfolded 120 x 66 x 129 cm (1)
Weight Electric scooter weight 25±1kgs
Use requirements Max. weight 100 kg
Min-max height 150-190cm
Age bracket >16 (2)
Technical
specications
Battery life Up to 52 km (3)
Max. speed 25 km/h
Max. inclination ≤20º
Operating temperature 25ºC
Storage temperature -10º/50ºC
IP protection rating IPX4
