9
1
6. Remove the LHS front mask
cover bolt above the bumper
.
7. Pull the foot brake fluid reservoir
out from the cover
.
8. Release the foot brake fluid
reservoir latch.
9. Pull the foot brake fluid reservoir
tube out from the latch gap.
97
99
