ASSE
1 Optical Tube 7 Tripod
2 Finderscope 8 Counterweight(s)
3 Finderscope Bracket 9 Counterweight Bar
4 Equatorial Mount 10 Declination Setting Circle
5 Latitude Adjustment Scale 11 Dovetail Mounting Bar
6 Tripod Center Leg Brace/Accessory Tray 12 Schmidt Corrector Lens
Figure 2.1 – Advanced Series
(Advanced C8-S Shown)
12
1
2
3
4
5
6
7
8
9
11
10
