5
1 Control Panel (see below) 8 Optical Tube
2 Focus Knob 9 Schmidt Corrector Lens
3 Star Diagonal 10 Fork Arm
4 Hand Control 11 Carrying Handle
5 Eyepiece 12 Right Ascension Locking Knob
6 Finderscope 13 Tripod
7 Finderscope Quick Release Bracket 14 Accessory Tray / Center Support Bracket
A Hand Control Port D Auto Guider Port
B Auxiliary Port s E On/Off Switch
C PC Interface Port F 12v Input Jack
7
6
4
2
1
11
12
9
3
8
13
14
5
10
A
B
C
D
E
F
Figure 2
