ENGLISH I 5
The Echelon Series features foldable rubber
eyecups to accommodate both eyeglass and
non-eyeglass wearers. If you do not wear
eyeglasses, leave the rubber eyecups in the up
position. If you wear eyeglasses, make sure
that the eyecups are folded down to obtain the
maximum field of view. When done observing,
make sure the rubber eyecups are in the up
position for storage.
EyEcup adjuStmENt
Fig 4
trIpod adaptaBILIty
The Echelon binoculars feature built-in threads
that allow the binocular to be attached to a
tripod using a binocular tripod adapter. These
threads can be accessed by unscrewing the
logo plate found on the front of the hinge
(Fig. 5). To attach the binocular to a tripod,
thread the adapter into the binocular and attach
the other end of the adapter to a photographic
tripod. Mounting the binocular on a tripod
allows for added stability and comfort during
prolonged viewing.
Fig 5
