3 | ENGLISH INSTRUCTION MANUAL
UNIVERSAL SMARTPHONE ADAPTER AND BLUETOOTH REMOTE
Attaching NexGO To Your Optic
NexGO is designed to work with many different optics, including telescopes, binoculars, spotting scopes, and even microscopes.
All these optics have different size eyepieces. NexGO’s clamp range can open from 25.4mm (1.0”) to 44.45mm (1.75”) to accom-
modate a variety of eyepieces.
1 2
3
To attach NexGO to your eyepiece, fi rst open the clamp (if
needed) by rotating the clamp knob.
Then position the clamp over your eyepiece.
Tighten the clamp and assembly onto the eyepiece by rotating
the clamp knob clockwise.
