13
3 Touch the test probe tips across the part under test.
4 Read the capacitance value in the display.
5 The display will indicate the proper decimal point and value.
Note: For very large values of capacitance measurement time can
be several minutes before the final reading stabilizes. The LCD
displays DSC when discharging. Discharging through the chip is
quite slow. We recommend the user to discharge the capacitor with
some other apparatus.
Low resistance measurement
WARNING: To avoid electric shock, disconnect power to the
unit under test and discharge all capacitors before taking any
resistance measurements.
1. Insert the red test leads banana plug into E2,P2 red com
jack,and black test leads banana plug into E1,P1 black com
jack.
2. At the range of 40 Ω, connect the clips to the low resistance’s
terminals, If the reading is too low then switch the range to 4
or 400m Ω.
3. Remove the clips from the low resistance terminals, and connect
then each other ,then press “ MODE/REL” button.
4 . Connect the clips to the low resistance’s terminal again.
5 . Read the resistance in the display. The display will indicate the
proper decimal point, value and symbol.
