Pg. 17V06232023
PARTS LIST
1 Right Station Assembly 100100 1
2 Left Station Assembly 100101 1
3 Upper Frame Assembly 100104 1
4 Lower Cross Brace 100102 1
5 Upper Cross Brace 100103 1
6 Guide Rod Bracket 100185 2
7 Guide rod 100122 4
8 Selector Stem Assembly 100183 2
9 Weight Selector Pin 100151 2
10 Weight Plate 100177 30
11 Rope 100172 1
12 Curl Bar 100184 1
13 Single Handle 100152 2
14 Chin Up Belt 100171 1
15 Height Adjustment Handle 100145 2
16 Rubber Bumper 100148 4
17 Hook 100174 2
18 M10×80 Allen Bolt 100187 4
19 M10×70 Allen Bolt 100188 8
20 M10×25 Allen Bolt 100189 4
21 M10×20 Allen Bolt 100190 4
22 M5×10 Allen Bolt 100191 2
23 #10 Lock Washer 100192 8
24 M10 Aircraft Nut 100193 8
25 #10 Washer 100194 24
26 Resistance Label Set 100178 2
27 Tablet Holder 100186 1
28 M6×75 Bolt 100195 1
29 #6 Washer 100196 2
30 M6 Nut 100197 1
31 Pulley Bracket 100110 2
32 Flat Washer Assembly 100115 2
33 Pulley 100173 2
34 Right Lock Switch 100108 1
35 Left Lock Switch 100109 1
36 M10×50 Allen Bolt 100201 2
37 #6 Allen Wrench 100224 1
38 #5 Allen Wrench 100225 1
39 #4 Allen Wrench 100226 1
40 #10Wrench 100227 1
To Next Page
