16
Alignment of reference points
▪ Mount the wall and floor base onto
the wall (see page 10 & 11). Place the
instrument onto the wall and floor base.
▪ Adjust the instrument as required by
rotating the wall and floor base.
▪ Slide the power switch forward for line
operation or back for dot operation.
When marking, always reference
the centre of the laser dot or line
i
The instrument must be placed on
a level surface to avoid inaccurate
measurement results.
i
