SITE CONSIDERATIONS
4. Fitting the padlock to the front bar
The padlock is supplied already tted to the front bar. In the event that it needs
to be retted, the following instructions detail the procedure for doing so.
FIGURE 3
FIGURE 5
FIGURE 7 FIGURE 8
FIGURE 4
FIGURE6
Unlock the discus padlock Locate the padlock enclosure on the front
bar
With the key in the lock, insert the discus
padlock through the opening from the
inside of the enclosure.
Turn the key clockwise to secure the
padlock in place.
Align the padlock with the hole, ensuring
that it is seated in the slot as shown in
Figure 4.
Ensure that the padlock remains in position
as shown in Figure 8.
