9
When using an internal transformer, minimal wire diameter must be 0.7 mm. check with
standard measuring equipment that there is no voltage in the electric circuit.
1. Remove the lower cover
2. Remove the high voltage cover and screw.
3. Remove the two screws and cable support.
4. Thread the electric wire through the right opening at bottom.
5. Connect the wires to the circuit by using the standard connector (included).
The connector can be pulled out for an easy connection.
6. Place the wires on the concave part and close with the two screws.
7. Close the high voltage cover with the screw.
8. Close the lower cover.
It is necessary to connect a two polar switch between the 110VAC/220VAC electric supply
and the controller.
The 110VAC/220VAC supply point, the circuit and connection to the transformer must
be performed according to Field Electrical Regulations by a licensed electrician who
is accredited with a license according to the Electrical Bill and security requirements.
NOTICE!
INSTALLATION AND
CONNECTION INSTRUCTIONS
Connecting the controller to power source
WARNING!
Use only the included built in transformer.
Any connection made between the irrigation controller to a power source or
any other electrical apparatus other than irrigation valves must be installed by
a licensed electrician.
WARNING!
In case the controller is supplied with a power supply cable connected to it, the
controller is for indoor installations only!
In order to use the controller for outdoor installation, a licensed electrician must
disconnect the power supply cable, and connect the controller according to the
instruction below.
If plug doesnt comply with local regulation, plug must be replaced by suitable
plug by licensed electrician.
