CONTROLS AND FEATURES
55
Tilt Lever and Steering Wheel Lock - (
3
)
A tilt feature allows the steering wheel angle to be adjusted to t
the operator. Pull on the lever and adjust the steering wheel for
comfort. Release the lever to lock the steering wheel tilt angle.
Gear Shift Lever - (
4)
The gear shift lever is located at the right side of steering wheel.
Use for changing the transmission gear selection. Apply brake
pedal before shifting gear, to ensure personnel safety.
L – Low Gear. The low speed range of the gearbox. It allows the
vehicle to move slowly with maximum torque at the wheels.
CAUTION
: To avoid damage to the CVT system, always use low
gear for constant slow speeds below 19mph (30 kph), pulling a
trailer, carrying heavy cargo, going over obstacles, or driving up
and down hills.
H – High Gear. The high speed range of the gearbox. It is for
normal driving speeds over 19mph (30 kph) and allows the
vehicle to reach maximum speed.
3
4
