CONTROLS AND FEATURES
67
Cargo Box and Tilt Feature - (
7
)
Refer to the safety decals on the cargo box for load information.
The cargo box has a release handle on each side that can
be used to tilt the box (maximum angle is less than 45°) for
maintenance or to dump material.
Seat - (
8
)
The driver’s seat offers fore and aft adjustment. To adjust the
seat, turn the lever to unlock it. Release the lever to lock the
seat into the desired position. Two storage boxes are located
under the driver and passenger seat for storing tools and other
items.
Removal of the driver seat allows access to the ECU and EFI
diagnostic connector located in the seat back area.
Removal: Pull up the rear part of seat
1
to release the grommet
pins, then pull out backward to remove the seat base tabs from
the slots.
Installation: Insert seat base tabs into the slots, then align the
grommet pin and press the seat to install.
1
