EFFECTIVITY
ALL CFM56 ENGINES
CFMI PROPRIETARY INFORMATION
CFM56-ALL TRAINING MANUAL
APPENDIX
BORESCOPE
INSPECTION
Page 158
Sep 03
BLADE QUANTITIES
Here is a table giving the quantity of blades on the
following rotors, for each engine model:
- The fan and booster rotor, where Stage 1 is the fan
rotor itself
- The high pressure compressor rotor
- The high pressure turbine rotor
- The low pressure turbine rotor.
