MAINTENANCE AND ADJUSTMENTS
DIFFERENTIAL GEAR OIL
1. Checking the differential gear oil level
2. Park the vehicle on a level surface.
3. Remove the differential gear oil filler bolt and check the oil level. It should be up to the brim of the
filler hole. If the level is low, add sufficient oil of the recommended type to raise it to the specified
level. NOTICE: Be sure no foreign material enters the
differential gear case.
4. Reinstall the differential gear oil filler bolt, and then tighten it to the specified torque.
Tightening torque: Differential gear oil filler bolt: 25 Nm (18 lb ft)
CHANGING THE DIFFERENTIAL GEAR OIL
1. Park the vehicle on a level surface.
2. Place a container under the differential gear case to
collect the used oil.
3. Remove the differential gear oil filler bolt and differential
gear oil drain
bolt to drain the oil.
-117-
