6-6 CLUTCH
Clutch Cover
Clutch Cover Removal
●
Removal:
Engine Oil (Drain, see Engine Oil Change in the
Periodic Maintenance chapter)
Right Frame Cover (see Frame Cover Removal
in the Frame chapter)
Clutch Cable Lower End [A]
Clutch Cover Mounting Bolts [B]
●
Turn the release lever [A] toward the rear
as shown, and remove the clutch
cover [B] About 90
o
[C].
To Next Page
