CFMoto 650NK - Torque Specifications

Fastener
Torque
Remarks
N·m kgf·m ft·lb
Electronic Fuel Injection(EFI)
Coolant Temp. Sensor 12 1.2 106in·lb
Speed Sensor Bolt 8 0.80 69in·lb L
Fuel Pump Bolts 5 0.5 — L,S
Oxygen Sensor 60 6.60 44.3
Cooling System
Radiator Hose Clamp Bolts 2.5 0.25 —
Water Pump Impeller Bolt 10 1.0 87in·lb
Water Pump Cover Bolts 10 1.0 87in·lb
Water Pump Drain Bolt 7.0 0.70 62in·lb
Thermostat Housing Bolts 10 1.0 87in·lb
Coolant Temp. Sensor 12 1.2 106in·lb
Baffl e Plate Bolts 6 0.60 52in·lb See text
Engine Top End
Valve Cover Bolts 10 1.0 87in·lb
Camshaft Cap Bolts 12 1.2 106in·lb S
Cylinder Head Bolts (M10 New Bolts) 54 5.5 40 MO,S
Cylinder Head Bolts (M10 Used Bolts) 49 5.0 36 MO,S
Cylinder Bolt (M8) 27.5 2.8 20 MO,S
Cylinder Nut (M10) 49 5.0 36 MO,S
Cylinder Head Bolts (M6) 12 1.2 106in·lb S
Cylinder Bolts (M6) 12 1.2 106in·lb S
Intake Manifold Bolts 12 1.2 106in·lb
Intake Manifold Clamp 2.0 0.2 1.5
Camshaft Chain Tensioner Bolts 12 1.2 12
Camshaft Chain Tensioner Nuts Mounting Bolts 20 1.2 20
Camshaft Sprocket Bolts 15 1.5 11 L
Spark Plug 15 1.5 11
Exhaust Pipe Manifold Holder Nuts 17 1.7 12
Muffl er Body Mounting Bolt (Front) 20 2.0 15
Torque Specifi cations
The following tables list the tightening torque for the major fasteners requiring use of a threadlocker.
Letters used in "emarks" column mean:
AL: Tighten the two clamp bolts alternately two times to ensure even tightening torque;
EO: Apply engine oil;
L: Apply a threadlocker to the threads;
Lh: Left-hand threads;
MO: Apply molibdenum disulfi de oil solution(mixture of engine oil and molybdenum disulfi de grease in a
weight ratio 10:1);
R: Replacement Parts;
S: Follow the specifi ed tightening sequence;
Si: Apply silicone grease (ex.PBC grease);
SS: Apply silicone sealant
2-6 PERIODIC MAINTENANCE
