9-6 CRANKSHAFT/TRANSMISSION
Item Standard Service Limit
Crankshaft, Connecting Rods
Connecting Rod Bend 0.04/100mm 0.2/100mm
Connecting Rod Twist 0.08/100mm 0.2/100mm
Connecting Rod Big End Side Clearance
0.15 ~ 0.30mm 0.55mm
Connecting Rod Big End Bearing Insert/
Crankpin Clearance
0.02 ~ 0.04mm 0.08mm
Crankpin Diameter: 37.984 ~ 38.00mm 37.97mm
Marking:
2 37.984 ~ 37.992mm – – –
1 37.993 ~ 38.000mm – – –
Connecting Rod Big End Inside Diameter: 41.000 ~ 41.016mm – – –
Marking:
1 41.000 ~ 41.008mm – – –
2 41.009 ~ 41.016mm – – –
Connecting Rod Big End Bearing Insert Thickness:
Marking:
Black 1.485 ~ 1.490mm – – –
Blue 1.490 ~ 1.495mm – – –
Green 1.495 ~ 1.500mm – – –
Connecting Rod Big End Bearing Insert Selection:
Con-rod Big End Bore
Diameter Marking
Crankpin Diameter Marking Bearing Insert
1 1 Black
12
Blue
21
2 2 Green
Specifi catons
