WHEELS/TIRES 10-4
Item Standard
Service Limit
Wheels (Rims)
Rim Runout:
Axial
Radial
Axle Runout/100 mm (3.94 in.)
Wheel Balance
Balance Weights
Rim Size:
Front
Rear
TIR 0.5 mm (0.02 in.) or less
TIR 0.8 mm (0.03 in.) or less
TIR 0.03 mm (0.0012 in.) or less
10 g (0.35 oz.) or less
10 g (0.35 oz.), 20 g (0.71 oz.), 30 g
(1.06 oz.)
17 × 3.50
17 × 4.50
TIR 1.0 mm (0.04 in.)
TIR 1.0 mm (0.04 in.)
TIR 0.2 mm (0.008 in.)
– – –
– – –
– – –
– – –
Tires
Air Pressure (when Cold):
Front
Rear
Tread Depth:
Front
Rear
Up to 180 kg (397 lb) load: 225 kPa
(2.25 kgf/cm², 32 psi)
Up to 180 kg (397 lb) load: 250 kPa
(2.50 kgf/cm², 36 psi)
6.5 mm (0.26 in.)
9.0 mm (0.35 in.)
– – –
– – –
0.8~1mm
0.8~1mm
Standard Tires:
Front
Rear
Make,
Type Size
CST TYRE
CST TYRE
120/70R17M/C(58H)
160/60R17M/C(69H)
WARNING
Use the same manufacturer’s tires on both front and rear wheels.
!
