BRAKES 12-5
Exploded View
No. Fastener
Torque
Remarks
N·m kgf·m ft·lb
1 Bleed Valve 7.8 0.80 69 in·lb
2 Brake Hose Banjo Bolts 25 2.5 18
3 Brake Pedal Bolt 8.8 0.90 78 in·lb
4 Rear Brake Disc Mounting Bolts 27 2.8 20 L
5 Rear Caliper Mounting Bolts 25 2.5 18
6 Rear Master Cylinder Mounting Bolts 25 2.5 18
7 Rear Master Cylinder Push Rod Locknut 18 1.8 13
B: Apply brake fl uid.
G: Apply grease.
L: Apply a non-permanent locking agent.
R: Replacement Parts
Si: Apply silicone grease (ex. PBC grease).
