SUSPENSION 13-3
No Fastener
Torque
Remarks
N·m kgf·m ft·lb
1
Front Axle Clamp Bolt 34 3.5 25
2 Front Fork Bottom Allen Bolts 30 3.1 22 L
3
Front Fork Clamp Bolts (Lower) 20 2.0 15 AL
4
Front Fork Clamp Bolts (Upper) 20 2.0 15
5 Front Fork Top Plugs 25 2.5 18
6. Outer Tube
AL: Tighten the two clamp bolts alternately two times to ensure even tightening torque..
G: Apply grease.
L: Apply a non-permanent locking agent.
R: Replacement Parts
