STEERING 14-3
No.
Fastener
Torque
Remarks
N·m kgf·m ft·lb
1 Front Fork Clamp Bolts (Lower) 20 2.0 15 AL
2 Front Fork Clamp Bolts (Upper) 20 2.0 15
3 Handlebar Holder Bolts 25 2.5 18 S
4 Left Switch Housing Screws 3.5 0.36 31in·lb
5 Right Switch Housing Screws 3.5 0.36 31in·lb
6 Steering Stem Head Bolt 108 11.0 80
7 Steering Stem Nut 20 2.0 15
AD: Apply adhesive.
AL: Tighten the two clamp bolts alternately two times to ensure even tighten torque.
G: Apply grease.
L: Apply a non-permanent locking agent.
Replacement Parts
S: Follow the specifi ed tightening sequence.
