ELECTRICAL SYSTEM 16-5
1. Alternator
2. Battery 12V10Ah
3. ECU
4. Fan Motor
5. Fuse Box with ECU Main Fuse
6. Meter Unit
7. Neutral Switch
8. Starter Motor
9. Coolant Temperature Sensor
10. Speed Sensor
11. Turn Signal Relay
12. Regulator/Rectifier
13. Side Stand Switch
Electrical System
Parts Location
14. Front Brake Switch
15. Oxygen Sensor
16. Crankshaft Position Senssor
17. Oil Pressure Sensor
18. Rear Brake Light Switch
19. Relay
20. Throttle Body
21. Ignition Coil
22. Ignition Switch
23. Fuel Fump (in the fuel tank)
24. Inlet Air Temperature Sensor
25. Roll-over Sensor
