-140-
EPS system
EPS indicator on the Dashboard will be on when EPS system is equipped to the vehicle. Normally,
EPS indicator will be on after ignition switch is turned to ON but EPS will not work.When the eng-
ine is started, EPS indicator will be off and EPS starts to function.
Trouble Code
Each trouble code consists of 2 digits,denoted by the times of long flash and short flash of EPS indicator.
Times of long flash represent the tens digit;
Times of short flash represent the single digit;
Duration of long flash: 2 sec.
Duration of short flash: 1 sec.
Flash interval: 1 sec.
The flash cycle will repeat after EPS indicator turns off for 3 seconds.
In case of an EPS failure, do not disassemble the EPS system. Check the wiring for
NOTE
