CAUTION
●The engine may overheat if the ATV is overloaded. If this happens, reduce the load to specification.
●After restarting, make sure that the temperature indicator is in the green area of side C. Continuous
use while the temperature indicator is in the red area of side H may cause damage to the engine.
Speedometer: shows the riding speed. In ODO mode , press and hold SETto toggle between KM and MP.
ODO/TRIP/RPM Toggle: Press and release SET to toggle among ODO mode, TRIP mode ,
RPM
mode
.
In TRIP mode，press and hold SET to return the trip display to zero.
Fuel Gauge: “F”Indicate the remaining amount of the gasoline in the fuel tank .
indicates the total amount
of fuel is 19L .
When the indicator reaches the first point of the red mark
,
fuel should be refilled as soon as
possible.The red mark indicates that the remaining fuel is only about 4.0L.
-64-
Features & Controls
