-92-
Engine oil
Always check and change the engine oil at the intervals
outlined in the Maintenance Schedule.
NOTE
Access cover grommets may come loose. Ensure they are in place before reinstalling the cover.
Maintenance & Lubrication
Engine oil check
1. Place the ATV on a level surface.
2. Start the engine and let it idle for 20~30 seconds. Stop the engine.
3. Wait a short period for the oil to settle.
4. Remove access cover by grasping the lower left portion and
5. Unscrew the oil dipstick out and wipe off with a clean cloth.
6. Insert the dipstick into the oil filler hole. Do not reinstall it.
7. Remove the dipstick again and check the oil level indication.
→
↘
1
2
Maintenance Procedures
pulling firmly.
1
2
Maintain the oil level between the upper and lower indicators.
8. Reinstall the dipstick into the oil filler hole, hand-tighten it, and
reinstall the access cover.
max
min
