Activation of RD and RC in a system with 2 hydraulic zones (with integrated or
external zone manager) controlled by BUS and ON/OFF devices (Fig. 5)
System containing the Cha oteaux product, to which BUS zone management acces-
sories are connected, such as Cha oteaux Expert Control and/or ON/OFF acces-
sories.
It is possible to remotely control the cooling function, if available.
Actions required (Fig. 6):
- Install the gateway by connecting it to the heating system via the BUS connection
- Replace the ON/OFF device with Cha oteaux Expert Control
ZONE
MANAGER
ZONE
MANAGER
GATEWAY
THERMOSTAT
EXPERT
CONTROL
EXPERT CONTROL
