73
CHAFFOLINK
7. GATEWAY OPERATING STATUS
LED CODES
The three LEDs on the side of the gateway allow you to have instant feedback on the
operating status of the product.
WEB LED (internet connection)
O Gateway is not powered or is OFF
Stable Green
Gateway correctly confi gured and connected to
the internet
Flashing Green (slow) Gateway waiting to be confi gured
Flashing Green (fast) Gateway connecting to the cloud
Stable Red
No connection to the service or
Gateway or not confi gured correctly
BUS LED (connection with products which have the BridgeNet BUS protocol)
O Gateway o
Stable Green BridgeNet Bus connection working
Stable Red BridgeNet Bus error or Bus cable is not connected
All LEDs
OFF Gateway o
Sequential fl ashing red Gateway startup
Flashing Green (ogni 5 sec.)
GATEWAY in operation (is enabled 2 minutes after
confi guration and disabled if there are errors, if the
button is pressed or the parameters are changed)
Flashing Green (alternating) Software update in progress
