13
CHAP. VIII Signaling
!Lights
1a
1d
1e
1f
2a
3a
1g
1b
1c
2b
2c
1h
6789:%;<=>?@%A%<BC<D8?E7%;<=>?@%A%FE=%;<=>?@5
- Remove the fixation screws
- Remove the bulb from its housing
- Turn the bulb support in the direction of the
arrow to remove the bulb
- Replace the bulb and reassemble the moun-
ting, being careful to maintain the joint position
.GHI:7%J;8?:%;<=>?5
- Remove the fixation screw
-
Push the bulb toward the screw to free the prong
- Replace the bulb and reassemble the moun-
ting, being careful to maintain the joint position
+<H<?<B=%;<=>?@5
- Remove the light cover with a screwdriver
which fits into the slot
- Replace the bulb, being careful to maintain
the lens position
- Replace the cap, red back
K7C%I789:%;<=>?%8BC%+"4%@<C:;<=>?@5
- Remove the two fixation screws
- Disconnect the wires
-
Replace the light and the connector by crimping
6789:%A%JE@<?<EB%+"4%;<=>?@5
- Removing the fastening screw
-
Remove the light assembly cover with a screw-
driver in the slot provided for this purpose
- Disconnect the wires
-
Replace the light and the connector by crimping
- Replace the light assembly covers
L;8@><B=%;<=>?@%;:C5
-
Remove the light assembly cover with a screw-
driver in the slot provided for this purpose
- Disconnect the wires
-
Replace the light and the connector by crimping
- Replace the light assembly covers
The signaling lights are standard bayonet lights
Stop / Road lights: white, 21 w / 5 w
Blinker lights: orange, 21 w
Back-up lights: white, 21 w
Fog lights: white, 21 w
License plate lights: shuttle, 5 w
Eclairages à Led
3rd brake light : JOKON 02818
JOKON 0207014
Sidelights JOKON 05024
Brake / position lights JOKON 13262
Flashing lights JOKON 13255
