SAFETY
A-18 521969D1 K Rev
FIG. 19: Warning - Hot Surface (2)
The safety sign is located under muffler on right side of
machine.
Avoid contact with hot surfaces. Exhaust piping and
engine components become hot during engine operation
and cool slowly after engine shutdown. Any contact with
hot surfaces can cause severe burns.
FIG. 20: Danger - Starter Bypass (3)
The safety sign is located on starter motor on left and right
side of machine.
Start engine from operator's seat only. Personal injury
could result from inadvertent machine operation if neutral
start switch or starter solenoid is bypassed.
FIG. 21: Warning - Hot Pressurized Coolant (4)
The safety sign is located underneath cover for expansion
tank.
Pressurized System: Hot coolant can cause serious
burns. To open cooling system filler cap, stop engine and
wait until cooling system components are cool. Loosen
cooling system pressure cap slowly to relieve pressure.
FIG. 19
FIG. 20
FIG. 21
