AC35 Magnetic Drill Press
Spare Parts List
Fig # Description Part # Qty
1 Set Screw M5X6 AC3501TQ 2
2 Cutter Arbor AC3502LQ 1
3 * Water Seal AC3503Q 1
4 *Arbor Spring AC3504Q 1
5 *Main Drive Spindle AC3505Q 1
6 *Woodruff Key M5x5x10 AC3506Q 1
7 *Oil Seal 22x32x7 AC3507Q 2
8 Gearbox Housing AC3508Q 1
9 Ball Bearing 6003zz AC3509Q 2
10 Retaining Ring R-35 AC3510Q 1
11 Bearing Ring AC3511Q 1
12 Final Drive Gear AC3512Q 1
13 Motor Nut M14 AC3513Q 1
14 Ball Bearing 608zz AC3514Q 4
15 Gear Pinion AC3515Q 1
16 1st Drive Gear 43T AC3516Q 1
17 Coolant Elbow Connector AC3517Q 1
18 Inner Gear Cover AC3518Q 1
19 Fan Guide AC3519Q 1
20 Ball Bearing 609 2RS AC3520Q 2
21B Armature 110V AC3521BQ 1
22 Stator Screw M5x55 AC3522Q 2
23B Stator Armature 120V AC3523BQ 1
24 Motor Housing AC3524Q 1
25 Brush Holder AC3525Q 2
26 Carbon Brush (pair) AC3526Q 2
27 Brush Cover AC3527Q 2
28 Motor Housing Screw M5x40 AC3528Q 2
29 Motor Housing Washer M4 AC3529Q 2
30 N/A
31 Motor Cord to Stand AC3531Q 2
32 Conduit Lead Sheath AC3532Q 1
33 Conduit Lead Clip AC3533Q 1
34 Conduit Lead Screw M4x12 AC3534Q 2
35 Motor Mounting Screw M8 X 16 AC3535Q 4
36 Machine Rack AC3536Q 1
37 Dovetail Slide AC3537Q 1
38 Dovetail Screw M6x20 AC3538Q 2
39 Coolant Bottle Bracket AC3539Q 1
40 Coolant Bottle Washer M5 AC3540Q 2
41 Coolant Bottle Screw M5 x 15 AC3541Q 2
42 Coolant Bottle AC3542Q 1
43 Coolant Bottle TAP (connector) AC3543Q 1
44 Plastic Coolant Tube AC3544Q 1
45 Cable Gland (Stand) AC3545Q 1
46 Main Body Casting AC3546Q 1
47 Adjustment Screw M5X20 for GIBS AC3547Q 5
48 Adjustment Screw Nut M5 AC3548Q 5
49 Guide Lock Knob M5 x 16 AC3549Q 1
50 Steel Strip Tensioner AC3550Q 1
51 Brass Guides (Pair) AC3551Q 2
52 Magnet Switch AC3552Q 1
53b Stop/Start Switch (Relayed) 115v AC3553bQ 1
54 Pinion Bushing AC3554Q 2
55 Pinion Washer 38x10x2T AC3555Q 1
56 Switch Panel AC3556Q 1
57 Panel Screw M4 x 12 AC3557Q 4
58 Panel Washer M6 AC3558Q 1
59 Pinion Hex Head Screw M6 x 16 AC3559Q 1
60 Switch Plate Bar AC3560Q 2
61 Pinion AC3561Q 1
62 Handle AC3562Q 3
63 Handle Knob AC3563Q 3
64 Side Panel AC3564Q 1
65 Side Panel Screw M4x8 AC3565Q 4
66 Wire Lead 16 AWG AC3566Q 3
67 Wire Lead 16 AWG AC3567Q 1
68 Main Rectifier Unit AC3568Q 1
69 Rectifier Nut M4 AC3569Q 1
70 Power Cord AC3570Q 1
71 Rectifier Screw M4x20 AC3571Q 1
72 Magnet AC3572Q 1
73 Arbor Support Bracket AC3573 1
74 Spindle Bush AC3574 1
75 Arbor Support Washer M8 AC3575 3
76 Arbor Support Screw M8x20 AC3576 3
77 Spanner Wrench M8 AC3577 1
78 Hex Key M2.5 AC3578 1
79 Hex Key M2.5 AC3579 1
80 Safety Guard Washer M6 AC3580 2
81 Safety Guard Butterfly Screw M6x8 AC3581C 2
82 Safety Guard AC3582 1
83 Safety Chain (Strap) AC3583 1
84 Electrical Connector AC3584Q 1
85 Coolant Bottle Brass Nut AC3585CQ 1
86 Coolant Bottle Washer 10x23x2 AC3586CQ 1
87 Coolant Bottle O-Ring 10.7x2 AC3587CQ 1
88 Motor Fixing Plate Screw M5x10 AC3588CQ 2
89 Motor Fixing Plate AC3589CQ 1
90 Flat Head Screw M4x6 AC3590CQ 4
91 Motor Back Cover Plate AC3591CQ 1
92 Sun Washer AC3592CQ 1
93 Spring Washer MG AC3593CQ 3
94 Screw M4x6 AC3594CQ 2
95 Wrench M8 AC3595CQ 1
96 Hex Key M2.5 AC3596CQ 1
97 Arbor Support Screw M8x70 AC3597CQ 2
98 Snap Ring S-28 AC3598LQ 1
99 Collar AC3599LQ 1
100 Return Spring AC35100LQ 1
101 Retaining Ring AC35101LQ 1
102 Set Screw M4x4 AC35102LQ 1
103 Lock Pin HRC63 AC35103LQ 1
104 Screw M3x6 AC35104LQ 1
105 Flat Spring AC35105LQ 1
106 Spring Washer M4 AC35106CQ 4
107 Flat Washer M4 AC35107CQ 4
108 Handle AC35108CQ 1
109 Cord Protector Sleeve AC35109CQ 1
Additional Parts for AC35
List Description
AC35-1220 1/2” Drill Chuck for AC35-451220/AC35-461220
AC35-451220 Drill Chuck Adaptor use with chuck AC35-1220
AC35-461220 Quick-Change Adaptor use with chuck AC35-1220
