Installation
VHR Cold Water Connection-
DH6000-VHR, DH6000T-VHR
Hot Water Connection- DH6000, DH6000T
55-75ºF / 13-24ºC
MINIMUM/MAXIMUM INCOMING
TEMPERATURE
46-50 PSI
MINIMUM INCOMING
SUPPLY FLOWING PRESSURE
INSTALL A ¾” OR LARGER FULL PORTSHUT-OFF VALVE IN THE WATER
SUPPLY LINE AS CLOSE TO THE DISHWASHER AS POSSIBLE FOR SERVICING.
WATER HARDNESS OF 3 GRAINS/US GAL - 0.83 IMP GAL - 5.3mg/L OR LESS.
18-20 PSI
MINIMUM/MAXIMUM
OPERATING FLOWING PRESSURE
CAUTION: To prevent damage to the dishwasher supply valves, the installing
plumber must thoroughly flush debris from the water supply line before
connecting it to the dishwasher. Damage caused by improper installation is not
covered by the limited warranty.
COLD
WATER
HOT
WATER
MINIMUM 3/4" NPT HOT WATER SUPPLY
110-140ºF/43-60ºC
MINIMUM/MAXIMUM INCOMING
TEMPERATURE
45 PSI / 310 kPa
MINIMUM INCOMING
SUPPLY FLOWING PRESSURE
INSTALL A ¾” OR LARGER SHUT-OFF FULL PORT VALVE IN THE WATER
SUPPLY LINE AS CLOSE TO THE DISHWASHER AS POSSIBLE FOR SERVICING.
WATER HARDNESS OF 3 GRAINS/US GAL - 0.83 IMP GAL - 5.3mg/L OR LESS.
18-20 PSI / 124-138 kPa
MINIMUM/MAXIMUM
OPERATING FLOWING PRESSURE
INSTALL A ¾” OR LARGER FULL PORT SHUT-OFF VALVE IN THE WATER
SUPPLY LINE AS CLOSE TO THE DISHWASHER AS POSSIBLE FOR SERVICING.
WATER HARDNESS OF 3 GRAINS/US GAL - 0.83 IMP GAL - 5.3mg/L OR LESS.
5
MINIMUM 3/4" NPT COLD WATER SUPPLY
