Installation
Drain Connection
DRAIN
CAUTION: The dishwasher drain connection must comply with all local plumbing,
health and safety codes. Damage caused by improper installation is not covered by
the limited warranty
GRAVITY DRAIN, 1-1/2" NPT CONNECTION
AUTOMATIC ELECTRIC DRAIN VALVE
MAXIMUM FLOW RATE: 15 US GPM/14 IMP. GPM/ 57LPM
Fig. 7
CAUTION:
Use caution when making drain valve plumbing connections.
NOTE:
Manually Operating the Drain Valve Instructions can be found on page 28.
6
