Supervisor Menus - Optional Champion Chemical Dispenser Set-up
IN-LINE Sensor Operation Error (A):
1. If the IN-LINE detergent sensor does not detect chemical within the 40 sec. prime cycle,
then, a ashing yellow bottle symbol
appears on the operation screen indicating
a 'DETERGENT LOW ALERT', (Fig. 34).
2. Check the chemical supply then press the
ashing bottle to run the pump 40 secs.
3. The ashing yellow bottle will disappear
when the IN-LINE sensor detects chemical.
Optional Champion Chemical Dispenser Set-up (continued)
IN-LINE SENSOR ONLY DETERGENT CYCLE TIMES (continued):
Fig. 34 - DETERGENT LOW ALERT - (ashing bottle)
IN-LINE Sensor Operation Error (B):
1. The detergent pump runs for 3 secs. before
each wash cycle. If the IN-LINE sensor does
not detect chemical after three consecutive cycles, the ashing yellow bottle will appear.
2. Check the chemical supply and press the ashing yellow bottle to reset the alert.
Repeating "LOW DETERGENT ALERT:
The ashing yellow bottle will continue to reset and periodically reappear until the cause of alert is repaired.
The dishwasher continues operating even with the error. CFA machines will lockout if there is a Low
Detergent Alert.
Fig. 35 - Tank sensor selected.
TANK Sensor Normal Operation:
1. Detergent pump output = 3ml/sec.
2. Machine lls.
3. When the lower oat is satised, detergent
pump runs for the ll set point to achieve
the initial detergent charge.
TANK Sensor Error Operation:
1. If machine has run one cycle, and tank temperature is 150ºF/65.6ºC or greater, and,
the tank sensor is not satised, then the detergent pump will pump the cycle time set
point.
2. Detergent pump waits 20 secs. and pumps the cycle time set point again or until
the sensor is satised.
3. When the wash pump is running, the detergent pump will run If the sensor dectects the
detergent is below its setpoint for 5 consecutive seconds.
4. This is repeated for two minutes or until tank sensor is satised. The ashing yellow
bottle "LOW DETERGENT ALERT" will appear if tank sensor is not satised within two
minutes.
Instructions for the Supervisor and Chemical Supplier
SUPERVISOR MENUS
(continued)
18
