Channel Plus 8051 - Page 3

Telephone Termination
Option 1 - old style
Black
Black
Green
Green
Yellow
Yellow
Red
Red
White/Orange
White/Blue
Orange
Blue
White/Brown
Brown
White/Green
Green
Pairs1&2
Pairs3&4
Dual Jack
Telephone Wallplate
Pairs3&4
Pairs1&2
RJ-14
Voice Grade Jacks
Cable Color Pin # Connector Color
Pin 1
White/Orange Pin 2 White/Orange
Blue Pin 3 Blue
White/Blue Pin 4 White/Blue
Orange Pin 5 Orange
Pin 6
N/C
N/C
Cable Color Pin # Connector Color
Pin 1
White/Brown Pin 2 White/Orange
Green Pin 3 Blue
White/Green Pin 4 White/Blue
Brown Pin 5 Orange
Pin 6
N/C
N/C
Option 2 - new style
Quickport wallplate
Model
8010
Model
8011
Model
8072
Cat5
4 pair UTP
Wire Color Codes
blue/white green
black
white
red
yellow
blue
blue
orange/white
orange
green/white
green
brown/white
brown
pair 1
pair 2
pair 3
pair 4
Band -Stripe
Twisted-Pair Wire
Solid Color
Twisted-Pair Wire
CAUTION: Quad wire is no longer acceptable
for installations in multi-line environments.
Retrofit with UTP if possible.
TIP
TIP
TIP
TIP
RING
RING
RING
RING
black
red
yellow
pair 1
pair 2
green
Quad Wire*
TIP
ACCESSORY
RING
GROUND
Modular connector designations
6 position connectors
8 position connectors
T
T
TT
R
RR
T
RTT
R
TRR
TT
R
RR
11
1
122
2
233
3
344
4
455
57
566
68
6
PR2
PR1
PR3
PR2
PR1
PR2
PR1
PR3
PR4
PR1
RJ-11
Single line
telephones,
answering machines
RJ-14
Dual line telephones
& answering
machines
RJ-25
Rare
3 line KSU hookups
RJ-45 (wired to TIA T568A standard)
Ethernet (both 10BaseT and 100BaseT)
Structured wiring of phones and data lines
(There are other wiring standards. For residential use,
w RJ-45 jacks are wired to the T568A
standard.)
e recommend that
